10
Fig. D
End milling function
11 – Angular bump (vertical)
12 – Gib stick of angular bump (vertical)
16 – Fixing handwheels of angular support (vertical)
46 – Milling table
47 – End milling cutter (not included in the scope of delivery)
48 – Brackets for cutter accessory
49 – Lever-stick for lifting/lowering/of milling table
50 – Flywheels for fixation of cutter accessory
51 – Fencing of end milling cutter
52 – Lock bracket for operating mode disabler
53 – Rod for operating mode disabler
54 – Fixing screws for brackets of cutter accessory
55 – Drill chuck
58 – Wrench for drill chuck
64 – Fixing screws for end mill fencing 51/knife’s end block fencing 65
54
52
53
51
12
16
64
55
58
47
11
48 50 46 49
