(7) GPIO (10-pin): GPIO Header
Pin 1
2
GPIO_30
2
GPIO_32
GPIO_34
GPIO_36
GND
GPIO_31
GPIO_33
GPIO_35
GPIO_37
VCC
(8) F_USB1 (9-pin): USB 2.0 Port Header
2
VCC
-DATA
-DATA
NC
GND
+DATA
GND
VCC
+DATA
Pin 1
(9) PS2KBMS (6-pin): PS/2 Keyboard & Mouse Header
GND
KB_CLK
KB_DATA
Pin1
MS_DATA
VCC
MS_CLK
(11) HDMI (20-pin): HDMI Header
Pin 2
HDMI Port Header
Pin 1
Pin NO.
Pin Definition
Pin NO.
Pin Definition
Pin 1
GND
Pin 2
HDMI_TXP2
Pin 3
HDMI_TXP1
Pin 4
HDMI_TXN2
Pin 5
HDMI_TXN1
Pin 6
GND
Pin 7
GND
Pin 8
HDMI_TXP0
Pin 9
HDMI_TXCP
Pin 10
HDMI_TXN0
Pin 11
HDMI_TXCN
Pin 12
GND
Pin 13
NC
Pin 14
NC
Pin 15
HDMI_SDA
Pin 16
HDMI_SCL
Pin 17
HDMI_+5V
Pin 18
GND
Pin 19
GND
Pin 20
HDMI_HPD
