4. Installation and connection
4.1 Dimension diagrams
RCMA421H dimension diagram and drawing for screw fixing
The front plate cover is easy to open at the lower part marked by an arrow.
Make sure that the installation area has been de-energised and
ensure compliance with the regulations for working on electri-
cal installations.
36 mm
90 mm
1
2
3
Zubehör/
Accessory
100 mm
116 mm
