5.3 Getting to know buttons and button functions
The table below lists the functions of the buttons when navigating through
the display, navigating through the menu and when making settings. From
"chapter 5.7 Making settings in the menu" in the menu onwards, just the rele-
vant button symbol is used to indicate that buttons have been pressed.
Button Button symbol Function
Up/
Test
 Call up next display
 Go to the next menu/submenu/cat-
egory item
 Activate parameter
 Change (increase) parameter value
 Press and hold down button for
more than 1.5 seconds: carry out the
manual self test.
Down/
Reset
 Call up next display
 Go to next menu/submenu
 Deactivate parameter
 Change (reduce) parameter value
 Press and hold down button for
more than 1.5 seconds: erase fault
memory
ENTER/
Menu
 Call up menu/submenu
 Apply modified parameter value
 Press and hold down button for
more than 1.5 seconds: Call up
menu/exit menu/go to next highest
submenu
