BENDIX AUTOVUE FLC-20 User Manual

22
Appendix A
SPN/FMI Codes to Service Action Codes
SPN FMI DTC Diagnostic Trouble Codes (DTC) Description
Service
Action Code
(See 2.11)
70
9 64 J1939: Engine controller message missing - CCVS1 M
19 149 J1939: Engine controller signal error - CCVS1 Parking Brake N
84
2 200 J1939: Engine controller signal invalid - CCVS1 Vehicle Speed P
9
64 J1939: Engine controller message missing - CCVS1
M
201 J1939: Engine controller signal missing - CCVS1 Vehicle Speed
19
64 J1939: Engine controller message missing - CCVS1 M
73 J1939: Brake controller signal error - EBC2 Wheel Speed N
190
2 179 J1939: Engine controller signal invalid - Engine Speed P
9 172 J1939: Engine controller signal invalid - EEC1 Engine Speed M
19 152 J1939: Engine controller signal error - EEC1 Engine Speed N
234 12 142 Internal Error A
597
2
74 J1939: Brake controller signal error - EBC1 Brake Switch N
19
625 9 72 Private CAN: Error frame threshold exceeded V
628 2
11 Internal Error A
36 Image Processor software version error
I
630
2
19 Calibration not complete
Q
47 SPC Calibration not complete
50 Dynamic Calibration out of range
51 Dynamic Calibration not complete
59 Vehicle Calibration not complete
19 198 Brake controller mismatch - Fusion
™
I
639
9
18 J1939 Bus Fault
M
31
879 9 184 J1939: Vehicle controller signal invalid - Left Turn Signal
881 9 185 J1939: Vehicle controller signal invalid - Right Turn Signal
904
2 178 J1939: Brake controller signal error - EBC2 Front Axle Speed P
9 131 J1939: Brake controller message missing - EBC2 M
19 151 J1939: Brake controller signal error - EBC2 Vehicle Speed N
Note: The system will not report newly active J1939 DTCs until the engine has been
running for 15 seconds. Do not attempt to diagnose J1939 DTCs without the engine running.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2, for troubleshooting assistance.
Appendix A (Pages 22–25)
APPENDIX A - SUSPECT PARAMETER NUMBER (SPN) AND FAILURE
MODE IDENTIFIER (FMI) CODES TO SERVICE ACTION CODES
Look up the SPN/FMI code found and see the Service Action Code to use. Table 2 in Section 2.11 (pages 11-14)
explains the service actions to take.
For an equivalent table sorted by Diagnostic Trouble Codes (DTCs) to service action codes, see Table 1 in Section 2.10
(pages 8-10).
