HD-14T Four Post Lift 10 P/N 5900037 — Rev. F — February 2022
Model HD-14T
Lifting Capacity 14,000 lbs. / 6,350 kg
Max capacity at Front Axle 7000 lbs. / 3175 kg
Max capacity at Rear Axle 7000 lbs. / 3175 kg
a Min. runway height
7.5" / 194 mm
b Maximum rise
82" / 2,083 mm
c Maximum lifting height
86.5" / 2,197 mm
d Overall width
1
127.5" / 3,239 mm
d1: 126 / 3,200 mm
e Outside length
205" / 5,205 mm
f Overall length
234" / 5,927 mm
g Height of post
101" / 2,543 mm
h Distance between posts
115.5" / 2,938 mm
i Drive-thru clearance
98" / 2,482 mm
j Runway width
20" / 508 mm
k Runway length
195" / 4,953 mm
l Width between runways
34.5" or 41.5" / 876 – 1,054 mm
m Runway centerline
54.5" or 61.5" / 1,384 or 1,562 mm
n Outside edge of runways
74.5" or 81.5" / 1,892 or 2,071 mm
Min. wheelbase @ rated capacity
2
135" / 3,429 mm
Min. wheelbase @ 75 capacity
2
115" / 2,921 mm
Min. wheelbase @ 50 capacity
2
100" / 2,540 mm
Min. wheelbase @ 25 capacity
2
80" / 2,032 mm
Maximum operating pressure 2,250 PSI
Safety Lock positions 17, spaced every 4" / 102 mm
Lifting time 65 seconds
Motor
3
220 VAC, 60 Hz, Single Phase
1
Overall Width is defined as the dimension outside to outside of the Baseplates. Use d1 measurement
listed above for creating Chalk Lines. The d measurement above includes the Bolt heads that stick out
near the bottom of the Posts used for securing the Safety Ladders.
2
The Lift supports less weight than its rated capacity if the Vehicle’s wheelbase is shorter; this is because
the wheels are closer to the middle of the Runways, where there is less strength. For example, the
maximum weight allowed on the Lift for a Vehicle with a wheelbase of 100" is 50 percent of the Lift’s
rated capacity (or 7,000 lbs. when the rated capacity is 14,000 lbs.).
3
Special voltages available upon request.
Specifications subject to change without notice
.
