HDS-14LSX / HDS-14LSXE Lifts 10 P/N 5900162 — April 2018 — Rev. F3
Model
HDS-14LSX HDS-14LSXE
Lifting capacity 14,000 lbs / 6,350 kg
Maximum capacity front axle
7,000 lbs / 3,175 kg
Maximum capacity rear axle
7,000 lbs / 3,175 kg
a Total width
130" / 3,304 mm
b Outside Posts length
213"/ 5,408 mm 243"/ 6,170 mm
c Total length (includes ramps)
241.5" / 6,132 mm 271.5" / 6,894 mm
d Post height
92" / 2,338 mm
e Runway thickness
7.5" / 192 mm
f Maximum rise
70" / 1,778 mm
g Maximum lifting height
77.5" / 1,970 mm
h Distance between Posts
120" / 3,050 mm
i Runway width
20" / 508 mm
j Width between Runways,
1
min.
37.5" / 953 mm
j Width between Runways,
1
max.
51.75" / 1,314 mm
k Runway length
199" / 16.5 feet / 5,054 mm 229" / 19 feet / 5,816 mm
l Min 4-wheel alignment
2
89" / 2,261 mm
m Max 4-wheel alignment
2
156" / 3,962 mm
n Max 2-wheel alignment
2
182" / 4,623 mm 212" / 5,385 mm
Min. wheelbase @ rated capacity
3
140" / 3,556 mm 165" / 4,191 mm
Min. wheelbase @ 75 capacity
3
120" / 3,048 mm 140" / 3,556 mm
Min. wheelbase @ 50 capacity
3
100" / 2,540 mm 115" / 2,921 mm
Min. wheelbase @ 25 capacity
3
80" / 2,032 mm 95" / 2,413 mm
Locking positions 15, spaced every 4" / 102 mm
Lifting time 60 seconds
Motor
4
220 VAC, 60 Hz, 1 Ph
1
May be limited if you are using Rolling Bridge Jacks.
2
Can vary depending on wheel size.
3
The Lift supports less weight than its rated capacity when the vehicle’s wheelbase is shorter; this is
because the wheels of such a vehicle are closer to the middle of the Runways, where there is less
strength. For example, the maximum weight allowed on the Lift for a vehicle with a wheelbase of
100" is 50 percent of the Lift’s rated capacity (or 7,000 lbs when the rated capacity is 14,000 lbs).
4
Special voltages available on request.
Specifications subject to change without notice.
