75
DIMENSIONS ARE IN MM
☺
3
1
2
REVISION
REV
DESCRIPTION
DATE
EDITED BY
ECO#
A
PRODUCTION RELEASE
12/10/2013
TM
00605
B
REPLACED 5525110 WITH 5525150
04/28/2014
TS
00649
NEXT ASSEMBLY
3ph POWER
UNIT BOX
ITEM NO
PART NUMBER
DESCRIPTION
QTY
REV
1 5525150
SPDT MICRO SWITCH;25A@125VAC
1
A
2 5525112
MICRO SWITCH COVER-5PA2
1
-
3 5530109
BHS 6-32 x 2.5
2
-
SHEET 1 OF 1
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
SIZE:
MATERIAL:
B
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT THE WRITTEN PERMISSION OF
BENDPAK INC.
IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED
.
TM
5215639
XPR CLEARFLOOR 3ph
MICROSWITCH KIT
---
---
12/10/2013
DO NOT SCALE DRAWING
1.5:1
SCALE:
THIRD ANGLE PROJECTION
--
--
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING
1.
