STEP 4
(Site Layout)
1. Determine which side of the lift will be the approach side.
2. Now determine where the power unit will be located.
The POWER SIDE column has the power unit mounting
bracket attached to the side.
3. Use the chart on page 13 to determine which lift width
layout you would like to use.
4. Once a location is determined, use a carpenters chalk
line to layout an alignment line for the post locations. Keep
all dimensions square within 1/8” (3mm) or malfunctioning of
the lift can occur. (See Fig 4.1)
5. After the post locations are properly marked, use chalk
or crayon to make an outline of the posts on the oor at each
post location using the post base plates as a template.
6. CHECK ALL DIMENSIONS TWICE and make sure that
the layout is perfectly square.
STEP 5
(Installing the POWER SIDE post)
1. Before proceeding, double the check measurements
and make certain that the base plate of each post are
aligned with the chalk line.
Fig 4.1
CHALK LINE
CHALK LINE
FOR XPR-10A CONFIGURATIONS USE NOTCHES TO ALIGN POSTS
FOR XPR-10 CONFIGURATIONS USE BASE PLATE EDGES TO ALIGN POSTS
FLOOR PLAN
NOTE:
BENDPAK LIFTS ARE SUPPLIED WITH INSTALLATION
INSTRUCTIONS AND CONCRETE FASTENERS MEET-
ING THE CRITERIA AS PRESCRIBED BY THE AMERI-
CAN NATIONAL STANDARD "AUTOMOTIVE LIFTS
- SAFETY REQUIREMENTS FOR CONSTRUCTION,
TESTING, AND VALIDATION" ANSI/ALI ALCTV-2006.
LIFT BUYERS ARE RESPONSIBLE FOR ANY SPE-
CIAL REGIONAL STRUCTURAL AND/OR SEISMIC
ANCHORING REQUIREMENTS SPECIFIED BY ANY
OTHER AGENCIES AND/OR CODES SUCH AS THE
UNIFORM BUILDING CODE (UBC) AND/OR INTERNA-
TIONAL BUILDING CODE (IBC).
