3209
COLLAPSED
3539
EXTENDED
SHEET 2 OF 2
REV
DWG. NO.
A
SIZE
TITLE:
J
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5210202
XPR-10 TOP
TROUGH ASSEMBLY
1:15
SCALE:
