BendPak XPR-9 Series User Manual

XPR-9 Series Two-Post Lifts 12 P/N 5900371 — Rev. D2 — May 2023
Model
XPR-9SBT XPR-9TF
Lifting Capacity 9,000 lbs. / 4,082 kg
Maximum Capacity –
Front Axle
4,500 / 2,041 kg
Maximum Capacity –
Rear Axle
4,500 / 2,041 kg
A – Rise 75.25 in. / 1,914.5 mm 69 in. / 1,753 mm
B – Lifting Height w/Pad* 77.207 in. / 1,961 mm 73.75 in. / 1,870 mm
C - Maximum Lifting Height* 83.25 in. / 2,117 mm 78.25 in. / 1,987 mm
D – Minimum Height w/ Pad 4.75 in. / 118 mm 4.75 in. / 118 mm
E – Height Overall 112.375 in. / 2,854 mm 123.25 in. / 3,128 mm
F – Width Overall 145 in. / 3,683 mm
(Fixed)
132 in. – 145 in. /
3,353 – 3,683 mm
G – Outside Posts
139.75 in. / 3,549 mm
124.75 in. – 137.75 in. /
3,169 – 3,499 mm
H – Inside Posts (Narrow)
118.5 in. / 3,009 mm
103.5 in. / 2,629 mm
H – Inside Posts (Wide) 116.5 in. / 2,959 mm
I – Drive-Thru Width (Narrow)
106 in. / 2,694 mm
91 in. / 2,311 mm
I – Drive-Thru Width (Wide) 104 in. / 2,642 mm
J – Front Arm Reach (Min) 25.5 in. / 646 mm 25.5 in. / 646 mm
J – Front Arm Reach (Max) 49.5 in. / 1,255 mm 49.5 in. / 1,255 mm
K – Rear Arm Reach (Min) 32.25 in. / 821mm 32.25 in. / 821mm
K – Rear Arm Reach (Max) 52.5 in. / 1,331 mm 52.5 in. / 1,331 mm
Floorplate Dimensions H: 1.375 in. / 35 mm
W: 6 in. / 150 mm
H: 1.5 in. / 37 mm
W: 8.5 in. / 216 mm
Safety Lock Positions 10 13
Standard Motor** 220 VAC, 60 Hz, 1 Phase
Time to Full Rise ≈45 seconds
Sound <43dB
* Lifting Height w/Pad is maximum lifting height with Pads at lowest height, no height adapter. Maximum
Lifting Height is maximum lifting height with Pads at top height and with the optional 2.5 in. / 63 mm
adapter.
** Special voltages available upon request.
Specifications subject to change without notice.
