3 - 16
Instrument and control functions
EN
3
1. Special key
2. Adjustment dial
3. Locknut
NOTICE
To avoid damaging the mechanism, do
not try turning over the maximum or
minimum setting.
Always have the shock absorber adju-
sted by a Benelli assistance centre.
WARNING
Read and understand the following in-
formation before handling the shock
absorber assembly.
• Do not tamper with or attempt to
open the cylinder assembly.
• Do not subject the shock absor-
ber assembly to an open ame or
other high heat source. This may
cause the unit to explode due to
excessive gas pressure.
• Do not deform or damage the
cylinder in any way. Cylinder da-
mage will result in poor damping
performance.
• Do not dispose of a damaged or
worn-out shock absorber assem-
bly yourself. Take the shock absor-
ber assembly to a Benelli dealer
for any service.
NOTICE
To avoid damaging the mechanism, do
not try turning over the maximum or
minimum setting.
Front suspension Standar
Hydraulic rebound brake -2 turns from all close posi
on
1
2
3
