Adjust the chain as follows:
1. Support the motorcycle on the side stand.
2. Loosen the rear axle nut.
3. Loosen the adjuster locknuts.
4. Turn the adjusting bolts to adjust the chain slack. Reference marks are provided on both sides of the
swingarm to help align the left and right adjustments. Tighten the axle nut, and adjuster lock nuts once the
chain slack is set at 10~20mm and conrm it a second time.
During regular maintenance, check the chain for the following conditions:
(1) Loose pins (2) Damaged rollers
(3) Rusty chain link (4) Twisted or snarled link
(5) Excessive free play (6) Loose chain
The sprockets are probably damaged if any above-mentioned problems are found on the chain.
Inspect the sprockets as follows:
INSPECTION& MAINTENANCE
Notice:
When installing a new chain, check both the front and rear sprockets for wear, they should normally be
replaced at the same time, as they wear each other out.
