Instruments and warning lights
The instruments and warning lights are activated by turning the ignition switch to the ON position.
After a preliminary check the displayed information reects the current general condition of the motorcycle.
1) High beam warning light (blue)
Lights up when the high beam is
activated.
2) Turn indicator light (green)
Lights up when the turn indicators
are activated.
3) Reserve fuel indicator (amber)
Comes on when approximately 5
litres of fuel are left; in this case, ll
up the tank as soon as possible.
4) Neutral indicator (green)
Lights up when the gears are in
"Neutral".
5) Injection warning light (orange)
Lights up in case of the fuel
injectors; in this case, contact an
authorized service center as soon
as possible.
6) Coolant temperature indicator
Indicates the cooling coolant
temperature expressed in Celsius
degrees (°C).
Warning lights
Multifunction
Display
7) Tachometer
Indicates the engine rpm
expressed in thousands.
8) Alarm Led
Lights up when the oil pressure
or the cooling water tempeare
not correct (more than
one anomalies may occur
simultaneously); at the
same time, the writings "OIL",
"HO" , "BAT" start ashing on
the tachometer in place of the
speed indication.
If the alarm led lights
up, immediately stop the
vehicle, allow it cool down
for a few minutes, check the oil
level rature or the battery
voltage and top up if necessary.
If the problem persists,
contact an authorized
service center as soon as
possible.
1
2
3
4
5
6
7
8
