85
The replacement of the fuses has to be performed only by a
Benelli Authorized service center.
Only in case of extreme urgency and if it is not possible to
have a specialized technical assistance, the operation can be
carried out by the owner according to the indications
provided below.
WARNING
Turn the ignition key on the "OFF" position
before checking or replacing the fuses, in
order to avoid a short circuit with
subsequent damage to other electric
parts of the motorcycle.
Replacing the fuses
6.11
40 Ah reload fuse
40 Ah supply fuse
The recharge fuse is located on the left side of the motorcycle,
in the position shown in the figure.
Service fuses are located under the seat; remove the saddle to
gain access to the fuses.
Remove the glovebox.
Replace the blown fuse and refit the cover.
The functions of the various fuses are given in the following
legend.
