68
MAX
MIN
Oil sight glass
6.5
Checking the engine oil level
Check the oil level while the engine is not
running, and has been allowed to cool
down for at least ten minutes after riding.
The check must be performed after placing
the motorcycle in an upright position on a
horizontal surface.
Level should be in between MAX and MIN
reference indicated on casing.
Top up if necessary.
WARNING
Do not start the engine if
the oil level is below the
MIN mark.
