June 2004 9507EM/5
2-13
2 to 9 Tonne Dumper Instruction Manual
Maintenance
Draining and Refilling Engine Oil
Ensure Engine Oil is Warm but NOT HOT!
z Ensure engine oil is warm but not hot. This will allow the
old oil to drain quicker and more thoroughly.
z Place a suitable receptacle under the engine drain plug. See
diagrams for drain plug location. The 5000, 6000, 7000 and
9000 Perkins engine models have a remote drain plug.
The Dumper MUST be On Firm Level Ground
When Checking or Changing the Oil
z Unscrew the drain plug and allow the old engine oil to drain
completely.
z Thoroughly wash the drain plug and renew the washer - if
fitted. Refit the drain plug.
z The engine oil filter MUST be changed when the engine oil
is renewed. See Engine Manufacturers handbook.
z Add the correct grade and quantity of engine oil to the engine.
See Engine Manufacturers handbook.
DO NOT OVERFILL
z Start the engine and check for leaks.
z Stop engine, leave for a few minutes and recheck engine oil
level. Top up as required. DO NOT OVERFILL.
Contaminated Water / Fluids / Oils Must Be Disposed of Safely
5, 6, 7 and 9 Tonne Perkins
4 Tonne Perkins
2 & 3 Tonne Hatz & Deutz
2 & 3 Tonne Hatz
2 & 3 Tonne Lister
5 & 6 Tonne Deutz / 2 & 3 Tonne Lister
