12/ 2017
BENNING PV 2
27
automatically. The “NFC” icon N is briey shown on the LC display
1
.
- After having called (RECALL) a storage location from the measured value memory of the
BENNING PV 2, rst press the
1
-key
K
to switch over the LC display
1
and write the
curve data to the NFC chip. The “NFC” icon N is briey shown on the LC display.
- As soon as the “NFC” icon N disappears, hold the NFC antenna of your Android device as
close and still as possible over the NFC logo
8
on the top of the BENNING PV 2 housing.
- The I-V characteristic will be transferred to the Android device and displayed.
Notes on data transfer:
- Protective pouches or covers of your Android device might affect data transfer. Remove
them before transferring data, if necessary.
- In the settings of your Android device, disable Android Beam, Samsung Beam or other
beams. The setting might affect NFC data transfer.
- Do not hold the Android device over the NFC logo
8
as long as the “NFC” icon N is shown
on the LC display
1
. Transfer might be impaired.
- If you do not know from the respective manual where the NFC antenna of your Android
device is located, slowly move the Android device over the surface of the BENNING PV 2
to establish a connection. Some Android device use the NFC logo on the housing surface
to locate the NFC antenna, whereas in other devices, the NFC antenna is located within the
battery area.
see gure 10: Representing the I-V characteristic via an Android device
8.8 Radio connection to insolation / temperature measuring instrument BENNING SUN 2 –
wireless SUN link
The BENNING PV 2 is able to receive the measured values (insolation, PV module / ambient
temperature and date / time stamp) of the insolation and temperature measuring instrument
BENNING SUN 2 (optional) via radio connection.
For this purpose, the BENNING PV 2 has to be coupled with the BENNING SUN 2 once.
Typical radio range of the BENNING SUN 2 in open space: approx. 30 m
Buildings / metal structures or interfering signals can reduce the radio range.
8.8.1 Coupling with BENNING SUN 2
- Remove all electronic devices in direct vicinity.
- Switch the BENNING PV 2 and the BENNING SUN 2 off.
- Press and hold the two ON/OFF keys of the BENNING SUN 2.
- Press and hold simultaneously the
R
ISO
-key
4
and the
Mode
-key
5
of the BENNING PV 2.
- The BENNING PV 2 indicates the successful coupling by means of an acoustic signal and
by displaying the serial no. of the BENNING SUN 2.
- The "W/m
2
" symbol is shown on the LC display
1
of the BENNING PV 2.
8.8.2 Decoupling from the BENNING SUN 2
- Remove all electronic devices in direct vicinity.
- Switch the BENNING PV 2 off.
- Press and hold the
R
ISO
-key
4
and the
Mode
-key
5
of the BENNING PV 2 for approx. 10
seconds.
- The BENNING PV 2 indicates the decoupling from the BENNING SUN 2 by means of an
acoustic signal and by clearing the LC display.
- The "R
PE
/Ω" symbol is shown on the LC display
1
of the BENNING PV 2.
8.8.3 Activating / deactivating the radio transmission of the BENNING SUN 2
- Couple the BENNING PV 2 with the BENNING SUN 2.
- To activate / deactivate the radio transmission, press and hold the -key of the
BENNING SUN 2 and simultaneously press the -key. A flashing triangle above the
-key shows that the radio transmission has been activated.
- If the BENNING PV 2 is within the radio range of the BENNING SUN 2, the measured insola-
tion value (W/m²) is shown on the LC display
1
of the BENNING PV 2.
- Besides the electric variables (Vo/c, Is/c, R
ISO
), an AUTO measurement by means of the
BENNING PV 2 additionally measures the insolation, the module and ambient tempera ture
as well as the date / time stamp of the BENNING SUN 2.
- If the BENNING PV 2 is outside the radio range of the BENNING SUN 2, the "W/m²" sym bol
on the LC display
1
starts flashing. Moreover, "_ _ _ _" is shown on the LC display
1
, if the
measured insolation value is outside the measuring range.
See gure 11: Radio connection to the optional insolation and temperature measuring instru-
ment BENNING SUN 2
Note:
If the BENNING PV 2 does not receive any radio signal from the BENNING SUN 2, the display
indications are stored with the date / time stamp of the BENNING PV 2.
