12/ 2017
BENNING PV 2
30
- Completely remove the defective fuse from the fuse holder.
- Insert the new fuse. Only use fuses of the same nominal current, nominal voltage, nominal
breaking capacity, tripping characteristic and dimensions.
- Lock the battery compartment cover into place on the bottom part and tighten the screw.
See gure 12: Battery/ fuse replacement
Note:
The PV test sockets
M
and
N
of BENNING PV 2 panel shorting circuitry are protected by a 15 A,
1000 V Solar fuse. This fuse is not operator replicable. If this fuse blows then the BENNING PV 2
will indicate an error before the panel is shorted, the BENNING PV 2 must be returned for
service.
9.6 Calibration
Benning guarantees compliance with the technical and accuracy specications stated in the
operating manual for the rst 12 months after the delivery date. To maintain the specied preci-
sion of the measurement results, the instrument must be recali brated at regular intervals by our
factory service. We recommend a recalibration interval of one year. Send the appliance to the
following address:
BENNING Elektrotechnik & Elektronik GmbH & Co. KG
Service Centre
Robert-Bosch-Str. 20
D - 46397 Bocholt
9.7 Spare parts
Fuse 500 mA, F, 1000 V, breaking capacity ≥ 500 A, D = 6.3 mm, L = 32 mm, P.no. 749771
10. Environmental notice
At the end of the product’s useful life, please dispose of it at appropriate
collection points provided in your country.
