BenQ MX813ST - Connecting Your Projector

Connection
18
Connection
When connecting a signal source to the projector, be sure to:
1. Turn all equipment off before making any connections.
2. Use the correct signal cables for each source.
3. Ensure the cables are firmly inserted.
• In the connections shown below, some cables may not be included with the projector (see
"Shipping contents" on page 8). They are commercially available from electronics stores.
• For detailed connection methods, see pages 19-24.
1. USB cable 5. Audio cable
2. HDMI cable 6. S-Video cable
3. VGA cable 7. Video cable
4. VGA to DVI-A cable 8. Component Video to VGA (DSub) adapter
cable
8
1
3
5
7
6
2
5
5
5
4
3
2
