BenQ MX813ST - Wall Mount Installation

Specifications
69
Wall mount installation
Minimum installation requirements
Computer
Resolution: XGA
Resolution: XGA
Diagram
Reference
SMART
Board
660
SMART
Board
680
Promethean
ActivBoard
164
Promethean
ActivBoard
178
RM
CkassBiard2
77.5
Hitachi
StarBoard
FX-63
StarBoard
FX-77
Image Diagonal
(inches)
D6477 64 78 78 63 77
Image Height
(mm)
H 975 1173 975 1189 1181 960 1173
Image Width
(mm)
W 1300 1565 1300 1585 1575 12800 1565
Distance from floor
to bottom of image
(mm)
f 900 900 900 900 900 900 900
Distance from
screen surface to
projector front
case (mm)
a 790 950 790 970 970 780 950
Distance from top
case to the top of
image(mm)
b 94 124 94 126 126 92 124
Distance from top
of wall mount to
ceiling (mm)
c5050 50 50 50 50 50
Minimum Ceiling
Height (mm)
e 2347 2575 2347 2593 2585 2330 2575
