Bentone B 30 2A - 2 Technical Data; Dimensions B 30 2 A

7 Bentone
165 205 48-2
2. Technical data
The burner is intended for:
• Light oil, B10 heating oil/biofuel blend (as defined in DIN V51603-6).
and is used for:
• Water heating generators.
• Hot air generators (these require LMO 24 255 C2E).
2.1 Dimensions B 30 2A
* Min. recommended distance to floor.
A Ø B Ø C D E F G H I * J
B 30 2A
174/315 108 108 372 220 281 303 188 395 200
2.1.1 Dimensions flange
ø108
160-190
35
14
H
I
A D
øB
øC
E
G
F
J
