Burner tube Length of Flange A Flange B Flange C
burner tube Measure B Measure B Measure B
E 77 524761
E 124 99 94 108
E 154 129 124 138
E 215 190 185 199
TECHNICAL DATA
DIMENSIONS
OUTPUT RANGE AND NOZZLES RECOMMENDED
Recommended Recommended
Burner tube Oil capacity Nozzle Pump pressure
kg/h kW Mcal/h Angle Size Type Bar
E 2,35-4,1 28-49 24-42 60°, 80° 0,50-1,00 S or R 10
The net calorific value of 11,86 kWh/kg for light oil has been used.
BURNER HEAD
E
RECOMMENDED NOZZLE
Because of different boiler types existing
on the market, with varying combustion
chamber designs, it is not possible to
Note that the spray angle and the
spray pattern change with the pump
pressure.
state a definite spray angle or spray
pattern.
171 215 21 04-01
6,0-8,0
2,4-3,2
10,0-11,0
(-1,0)-0,0
Flange A
Flange B
Flange C
B
ø89
202
155
94
148
296
7
ø89,5
21
130-150
ø89,5
26
ø89,5
12
130-150
130-150
10,5
12
12
-0,2
0,0
0,2
0,4
0,6
0,8
1,0
1,2
2,0 2,5 3,0 3,5 4,0 4,5
