Bentone LMO14.113C2E - Page 23

23 Bentone
165 105 41
6. Pump Suntec D(V) 57C
Technical data
One or two-pipe system.
Viscosity range: 2 - 75 mm²/s
Pressure range: 10 - 28 bar
Rated voltage of coil: 220/240V 50/60 Hz
Oil temperature: max 90°C
Components
1. Suction
2. Return and internal by-pass plug
3. Nozzle outlet
4. Pressure gauge port
5. Vacuum gauge port
6. Pressure adjustment






