Bentone LMO14.113C2E - Working Field; Setting for Nozzle Assembly and Air Damper; Burner Installation

7 Bentone
165 205 61-2
2. Technical data
The burner is intended for:
• Operation in installations according to EN 303 and EN 267.
When operating with a hot air boiler, the LMO24.255 or LMO44.255 control unit must be used.
Fuels:
• FAME/RME according to EN 14214.
• Fuel oil according to DIN 51603-1.
• Fuel oil A Bio 10 according to DIN 51603-6.
2.1 Dimensioner B 40 A
* Min. recommended distance to oor.
J
Ø B
Ø C
H
I
A
D
E
F
G
A Ø B Ø C D E F G H I * J
172/272/372 126 114 420 260 310 360 195 400 200
