LED surgical lights, single and combination lights CHROMOPHARE
®
E 778, E 668, E 558
Technical Data
23
CHROMOPHARE
®
E 668 Specifications Value Unit
Weight incl. transformer 60 kg
Max. torque 495 Nm
Light head diameter 64 cm
Light emission surface area 2352 cm
2
Max. swivel radius 233 cm
Lowest position of light head (N.C.) 128,5 cm
Highest position of light head (N.C.) 228 cm
Lowest position of light head (A.C.) 115 cm
Highest position of light head (A.C.) 220 cm
Clearance, single light (N.C.)
(with a 245.5-cm ceiling height)
200 cm
CHROMOPHARE
®
E 558 Specifications Value Unit
Weight incl. transformer 58 kg
Max. torque 445 Nm
Light head diameter 58 cm
Light emission surface area 1766 cm
2
Max. swivel radius 229,5 cm
Lowest position of light head (N.C.) 128,5 cm
Highest position of light head (N.C.) 229 cm
Lowest position of light head (A.C.) 118 cm
Highest position of light head (A.C.) 223 cm
Clearance, single light (N.C.)
(with a 245.5-cm ceiling height)
200 cm
