Berchtold CHROMOPHARE E 778 - 8 Swivel Arm

LED surgical lights, single and combination lights CHROMOPHARE
®
E 778, E 668, E 558
Swivel arm
58
8 Swivel arm
Position Part No. Description
1 79695 Central column for single lights
79696 Central column for double lights
2 231 Screw DIN 966 - M 3 X 16-A2
3 78862 Cover blue Ø 70 mm
4 78979 Counter sunk head screw
5 78864 Cover for suspension
6 228 Screw, M3 x 0.5x10
7 78959 Bush
8 75187 Cover
9 78870 Jar cover
10 78867 Brake screw
