Berchtold CHROMOPHARE E 778 - Maintenance; Function Tests before each Use; LED Modul Replacement

LED surgical lights, single and combination lights CHROMOPHARE
®
E 778, E 668, E 558
Maintenance and inspection
89
13.4 Maintenance
13.4.1 Function tests before each use
 To be completed by the operator.
Each day, before using the CHROMOPHARE

lights, perform the
function tests described at the beginning of the Operation
section.
13.4.2 LED modul replacement
 Performed by BERCHTOLD or a company authorized by
BERCHTOLD.
CAUTION!
Property damage due to unauthorized
replacement of LED modules!
If defective LED modules are replaced by
insufficiently qualified persons, significant damage
to property can result.
Any and all implied warranty claims will also be
invalidated by non-compliance!
Therefore:
– LED modules may only be replaced by
BERCHTOLD or a company authorized by
BERCHTOLD.
Fig. 52 Overview LED modules
Numbering of the LED modules begins at the side shaft
bearing counted clockwise
