LED surgical lights, single and combination lights CHROMOPHARE
®
E 778, E 668, E 558
Connecting the electricity
71
11.2.3 Electrical connections with wall control box
Connections on ceiling tube
Fig. 38 Ceiling flange connections
Ceiling tube of the CHROMOPHARE
®
surgical light.
Position Circuit Boards
1 230 V connection
2 CAN distribution board: Connection for
wall control box (wall box)
Combination lights have additional terminal pairs that must also
be connected.
