6. Technical data (input voltage 3 x 380...460V)
Inverter
ACM-D2
7.5kW 11.0kW 15.0kW 22.0kW 30.0kW 37.0kW
Motor output kW 7.5 11.0 15.0 22.0 30.0 37.0
Output power kVA 11 16.5 22.5 33 45 55
Rated device current A 15.6 22.5 30 43 58 71
Overload capacity %
200% × 180 s (+/-15%)
Output voltage
(max. = mains voltage)
V 3 x 0...U
IN
Output frequency Hz 0...650 Hz (0...1300Hz vers. D2A-1300-xxx)
Electrical efficiency % > 95%
Operating mode 4-quadrant operation (with braking chopper)
Mains voltage V 3 x 380...460V, (-15% +10%)
Mains frequency Hz 40...70 Hz
Modulation method PWM
Modulation frequency kHz 4 3
Speed reference
0...10V DC; (10...0V DC); -10V...0...10V DC
0...20mA; 4...20mA
External potentiometer (4K7); Keypad (JOG mode)
Motorpotentiometer ((mode JOG MPt) only with softw. D2A-STD)
RS485 (CAN on request)
Frequency resolutions Hz 9 Bit of maximum frequency
Acceleration/
deceleration time
Sec. 0.01...1000 sec.
Maximum frequency Hz 0...650 Hz (0...1300Hz vers. D2A-1300-xxx)
Minimum frequency 0...Fmax
DC brake Standard
Braking chopper Standard
Undervoltage trip level V 280V AC / 395V DC
Overvoltage trip level V 537V AC / 760V DC
Short circuit Electronically controlled
Overcurrent Electronically controlled
Overtemperature Monitoring of heat sink temperature
Programming block Definable security code
Start block Definable AUTOSTART function
Ambient temperature °C
From −5 °C to 45 °C
Storage temperature °C
From −20 °C to 60 °C
Humidity % < 90% RH, non-condensing
Degree of protection IP IP 20
Weight, approx. kg 8.5 8.7 21 21 22 26
Inverter output
data
Mains
input
Control dataProtective
functions
Ambient
conditions
BERGES electronic
8 Operating manual ACM-D2 29.05.98
