19. Functions of ACM-D2
Function
Page
Works
setting
(Default)
Adjustment range
Customer
setting
Design. Description
1 Output frequency indication 30 - -
2 Motor voltage indication 30 - -
3 Maximum output frequency 30 50 Hz
6...650 Hz
(12...1300 Hz *)
4 Minimum output frequency 30 0 Hz 0...Fmax
5 Acceleration time ramp 1 31 2.5 sec. 0.05...1000 sec.
6 Deceleration time ramp 1 31 2.5 sec. 0.05...1000 sec.
7 U/f-ratio 31 50 Hz
30...650 Hz
(30...1300 Hz *)
8 BOOST 31 5 % 0...40 %
8+ Dynamic BOOST 32 0 % 0...50 %
8- U/f ratio reduction 32 20 % 0...20 %
9 Static torque time 32 2 sec. 0...25 sec.
U Frequency threshold FX1 32 50 Hz 0...Fmax
JOG JOG Mode and motorpotentiometer 33 OFF ON - OFF - MPt1 - MPt2
u Frequency threshold FX2 34 10.0 Hz 0...Fmax
I Motor current indication 34 - -
S Motor current limit 34 150 % 0...200% - rem
S-INT
Inverter behaviour at the current
limit value
35 0 0...4
DY
Delay time at the
current limit value
35 5 sec. 0...20 sec.
HYS Current limit hysteresis 35 3 % 2...30 %
s Slip compensation frequency 36 0 Hz 0...20 Hz
x
Frequency threshold
slip compensation
36 0.5 Hz 0...30 Hz
zero No-load current 36 0 0...110
A Preset frequency FFIX1 37 +5 Hz
-650..0..+650 Hz
(-1300..0..+1300 Hz *)
B Preset frequency FFIX1 37 +10 Hz
-650..0..+650 Hz
(-1300..0..+1300 Hz *)
C Preset frequency FFIX1 37 +20 Hz
-650..0..+650 Hz
(-1300..0..+1300 Hz *)
a Skip-band 1 Lower limit 37 0 Hz
0...650 Hz
(0...1300 Hz *)
A Skip-band 1 Upper limit 37 0 Hz
b Skip-band 2 Lower limit 37 0 Hz
B Skip-band 2 Upper limit 37 0 Hz
c Skip-band 3 Lower limit 37 0 Hz
C Skip-band 3 Upper limit 37 0 Hz
d Skip-band 4 Lower limit 37 0 Hz
D Skip-band 4 Upper limit 37 0 Hz
DC DC brake voltage 38 15 % 0...50 %
t DC brake time 38 0 sec. 0...20 sec.
E Acceleration time ramp 2 38 5.0 sec. 0.05...1000 sec.
F Deceleration time ramp 2 38 5.0 sec. 0.05...1000 sec.
TAB1
SUB IMOTSUB SLIP
SUB FFIXSUB FEXC
BERGES electronic
56 Operating manual ACM-D2 29.05.98
