Berges ACM-D2 2.2kW - Page 59

Function
Page
Works
setting
(Default)
Adjustment range
Customer
setting
Design. Description
CLIP Clipping 39 2 0...15
FILTER Speed reference filter 40 3 0...6
L1 ENABLE input 40 LOW HIGH - LOW
L2 REVERSING input 40 LOW HIGH - LOW - OFF
L3 START/STOP input 40 LOW HIGH - LOW
L4 PRESET FREQ. SEL. 1 input 40 LOW HIGH - LOW - OFF
L5 PRESET FREQ. SEL. 2 input 40 LOW HIGH - LOW - OFF
L6
RAMP SELECTION or
MOTORPOTENTIOMETER input
40 LOW HIGH - LOW - OFF
L7
MOTORPOTENTIOMETER or
DC - Brake input
40 LOW HIGH - LOW - OFF
L8
DC - Brake or
ACM - SYNCHRONIZER input
40 LOW HIGH - LOW - OFF
REF
Speed reference selection 41 1 1...5
Fk Speed reference scaling 41 100% 40...100%
AO
Fine tuning output frequency
(Only with softw. D2A-STD)
42 0% 0...100%
SIO SIO address 42 OFF OFF..1..127 (1...15) *
BrLim Dynamic braking protection 43 0 0...15
MOD Modulation degree 43
230V 230
400V 245
0...255
FFB BOOST form factor 43 196 quad...0...255
PASS PASSWORD 44 - -
SECUR Security code 44 0 0...2
SET SET PASSWORD 44 0 0...999
TAB2
SUB LOG
SUBREF
BERGES electronic
29.05.98 Operating manual ACM-D2 57
