Function
Page
Works
setting
(Default)
Adjustment range
Customer
setting
Design. Description
SOLL
Speed reference signal
(terminal 8 or 29)
45 - -
ANA Input AN-IN/OUT 45 - -
Port E Status PortE 45 - -
Port A Status Port A 45 - -
U27 Status U27 45 - -
U31 Status U31 45 - -
U1 Status U1 45 - -
U2 Status U2 45 - -
ERROR 1 Last error indication 45 - -
ERROR 2 2.nd error indication 45 - -
ERROR 3 1.st error indication 45 - -
Software: Software release 45 - -
00000:00 Operating hours counter 45
Aout Analog output configuration 45 0 0...2
Fm Full scale frequency value 46 50 Hz
5...650 Hz
(10...1300 Hz *)
SW1 DC brake configuration 46 ON ON - OFF
SW2
START/STOP and
REVERSING configuration
46 OFF ON - OFF
SW3 Error reset (Autoreset) 46 ON ON - OFF
SW4 Fmin configuration 47 ON ON - OFF
SW5 Error signalling relay configuration 47 ON ON - OFF
SW6 DC-brake trigger 47 OFF ON - OFF
SW7 Autostart function 47 ON ON - OFF
SW8 "S" ramp function 48 OFF ON - OFF
R_Sel 2.nd set of ramp time selection 48 0 0...4
REL Config. relay output term. 19,20 49 +3 -11..0..+11
OC1 Config. open coll. OC1 term. 21 49 -2 -11..0..+11
OC2 Config. open coll. OC2 term. 22 50 -0 -11..0..+11
DIS
Display indication on
TAB1, function 1
50 0 0...8
BERGES Power-on messagge 51 BERGES
Set of eight
alphanumeric signs
L
Display brightness
(only with ACTIVE display)
51 42 % 14...100%
* Vers. D2A-1300-xxx
TAB3
SUB DIAG
SUB XPARSUB DIS
BERGES electronic
58 Operating manual ACM-D2 29.05.98
