Recall factory settings
TAB1
The original factory settings for all parameters can be restored by pressing both INC
and DEC simultaneously for 5 sec. A blinking "DEFAULT" indicates that recalled para-
meters are not stored. To store the recalled parameter values into the non volatile in-
verter memory execute the SAVE - function.
The recall of default parameter values can change the drive
system caracteristics subtiantially.
Save parameter
TAB1
By pressing both INC and DEC simultaneously the parameter values are stored in the
internal non-volatile inverter memory. At the end of the Save-function the program re-
turns to TAB1, func. 1.
15.3. Program level TAB2
Program level TAB2
TAB2
The program level functions in TAB2 allows to configure analog and digital inputs and
to program the BOOST characteristic, the maximum output voltage and the security
features of the inverter.
Enter program level TAB3
TAB2
The program level functions in TAB3 allows to configure the outputs, to access the dia-
gnostic utilities and to program extended parameters.
To enter program level TAB3 press both SHIFT and SELECT simultaneously.
Function CLIP: Clipping of speed reference signal
TAB2
This parameter allows to cut the speed reference signal at lowest frequencies in order
to reduce the effect of noise on the speed reference line
A speed reference signal below the limit as defined by the fellowing formula is cut to
zero.
Limit = N∗
Fmax
512
N.... CLIP parameter value
Range: 0...15
Default: 2
DEFAULT
SAVE ??
TABLE 2
SUB TAB3
CLIP 2
BERGES electronic
29.05.98 Operating manual ACM-D2 39
