Berges ACM-D2 2.2kW - 15.3. Program level TAB2

Function DC: DC brake voltage
TAB1
This parameter controls the amount of DC voltage applied to the motor windings du-
ring activation of the DC-brake. The DC-brake is activate during the time when
term. 30 is activated and after deactivation of term. 30 for the time set by TAB1,
func. t. Depending on TAB3, SUB XPAR, func. SW1 the motor may automatically re-
start at the end of DC-brake.
If a long DC-brake time is programmed, excessive motor
heating may result.
Range: 0...50%
Default: 15%
Function t: DC brake time
TAB1
After deactivating term. 30 the DC-brake will remain active for the period set by this
parameter.
The motor may restart automatically at the end of the DC-brake
time depending on TAB3, SUB XPAR, func. SW1.
Range: 0...20 sec.
Default: 0 sec.
Function E: Acceleration time ramp 2
TAB1
This parameter sets the time to accelerate the motor from 0 to 50 Hz.
Use the following formula to determine the proper time for other frequencies:
Tx=50∗
TACC
FEND
T
X
: Time to set
T
ACC
: Acceleration time
F
END
: End frequency
Ramp selection is controlled by term. 25.
Range:
0.05...1000 sec.
Default: 5.0 sec.
Function F: Deceleration time ramp 2
TAB1
This parameter sets the time to decelerate the motor from 50 to 0 Hz.
Use the following formula to determine the power time for other frequencies:
Tx=50∗
TDEC
FEND
T
X
: Time to set
T
DEC
: Deceleration time
F
END
: End frequency
Ramp selection is controlled by term. 25.
Range:
0.05...1000 sec.
Default: 5.0 sec.
DC 15%
t 0.0s
E 5.0s
active ramp term. 25
ramp 1
ramp 2
OFF
ON
F 5.0s
active ramp term. 25
ramp 1
ramp 2
OFF
ON
BERGES electronic
38 Operating manual ACM-D2 29.05.98
