Function FILTER: Speed reference filter
TAB2
The speed reference signal can be filtered by a digital filter. The line constant of the fil-
ter is set by this parameter.
Range: 0...6
Default: 3
Submenu logic levels of digital inputs
TAB2
The logic level of digital inputs can be changed between HIGH-and LOW-active. Inputs
(except ENABLE and START/STOP) may be deactivated by setting the corresponding
parameter to OFF.
Any change in this submenu becomes active after a save and a restart of the inverter
(Soft-Reset or POWER ON - Reset). A point in the display indicates that parameter va-
lues were modified but not saved.
ENABLE term. 11 (OFF not possible)
REVERSING term. 15
START/STOP term. 16 (OFF not possible)
PRESET FREQ. 1 term. 23
PRESET FREQ. 2 term. 24
RAMP SELECT term. 25
Motorpotentiometer (increase frequency)
(TAB1, func. JOG = MPt)
Motorpotentiometer (decrease frequency) term. 26
(TAB1, func. JOG = MPt)
DC - Brake when ACM - Synchronizer (Option) is used
(activation ACM - Synchronizer with L8 = OFF)
DC BRAKE term. 30
ACM - Synchronizer (OFF)
SUB LOG
Range:
HIGH, LOW, OFF, ON
Default: LOW
Submenu speed reference
TAB2
The functions in the submenu SUB REF permit configuration and selection of the
speed reference.
To enter the submenu press both SHIFT and SELECT simultaneously.
FILTER 3
SUB LOG
L1 LOW
L2 LOW
L3 LOW
L4 LOW
L5 LOW
L6 LOW
L7 LOW
L8 LOW
SUB REF
