Submenu DIAGNOSTICS
TAB3
Speed reference signal indication on term. 8 or 29 (dig. 9 bit 0...511)
Input AN-IN/OUT term. 17 (configuration mode 1, see page 21)
Status of port E
Status of port A
Status of U27
Status of U31
Status of U1
Status of U2
Last error
2.nd error
1.st error
Software release NAME/REL Nr./DATE/TYPE (scrolling text)
Operating hours counter
Hours
Minutes
SUB DIAG
Function Aout: Analog output
TAB3
This parameter defines what the analog meter output (term. 13) will indicate.
Range: 0...2
Default: 0
SUB DIAG
SOLL xx
ANA xx
PortE
PortA
STAT U27
STAT U31
STAT U1
STAT U2
Error1
Error2
Error3
Software:
XXXXX:XX
A.out 0
Parameter value Description
0
Output proportional to Fout. The frequency value
corrisponding to full scale (10V) can be set in TAB3, func. Fm.
1
Output proportional to output current. Full scale (10V) = 200%
of inverter rated device current.
2
Digital frequency indication. Square wave signal
corrisponding to the motor frequency. (10V, duty cycle 50%).
This parameter can only set, when the value in TAB2,
function SIO is OFF.
BERGES electronic
29.05.98 Operating manual ACM-D2 45
