Determine Location for
Recirculation Grill Install the grill in
the center support wall (see photo
showing outline for cutout marked on
center support wall)The opening
should be positioned in front of where
the NITE Phoenix unit will be
positioned. The size should be 11-1/2″
x 4-5/8″. Use provided template for
marking.
Cut Opening for
Recirculation Grill
Cut an opening (A) with a metal-
cutting air saw or jigsaw for the
recirculation grill in the support wall.
Attach grill (B) to the center wall using
black Phillips head screws.
NOTE: Take precautions not to damage
carpet or upholstery.
