Determine Location for the
NITE Phoenix Duct Next to
Window. Set duct on top of
decking on the driver’s side of
the sleepers back wall. Center
duct between window and corner
seam, mark the aluminum
decking plate around the bottom
of duct (A), remove duct and cut
opening (B).
Attach Control Panel to the
NITE Phoenix Duct. Carefully
depress the lock and remove the
controller cover.
Install the controller to the
duct using #10 x 1/2″ T 20
torque head screw (PN 600129).
Do not over tighten. Replace
cover.
The following steps vary based on whether the sleeper has a
window or not. If the sleeper has a window, continue with step 12.
If the sleeper does not have a window, proceed to step 24.
