OPTIONAL ACCESSORIES
The following optional presser feet specially prepared
for this machine are available at extra–charge.
The snap–on type presser foot of this machine permits
easy removal and replacement.
Snap–On Type Presser Foot
• Removal
– Turn the handwheel to raise the needles to the
highest position.
– Raise the presser foot.
– Press red colored lever (A) located on back of
clamp under the presser foot shank, raise
presser foot shank to its High Lift position and
while holding the presser foot shank in this
position, remove the presser foot sole.
• Replacement
– Place presser foot sole on stitch plate under
presser foot shank so that hinge pin (C) will fit
in slot (B) of the shank. Then lower presser foot
shank.
– If presser foot sole can not be placed under
presser foot shank easily, raise presser foot
shank to its High Lift position and while holding
it in this position, place presser foot sole under
presser foot shank. Then lower presser foot
shank.
– Raise presser foot shank and make sure the
presser foot sole is properly attached to the
presser foot shank.
PLEASE NOTE:
Do not use presser foot made for other machi-
nes. Use of such presser foot may result in inter-
ference with the needle and knife and can be
hazardous.
