Bernette Funlock B42 - Threading the Center Coverstitch;Chainstitch Needle (Green)

20
Threading the Center Coverstitch/
Chainstitch Needle (Green)
(D on Needle holder)
– Raise the presser foot to open the tension
discs.
– Thread the Center Coverstitch/Chainstitch
needle as indicated (1)–(10).
2
3
4
1
5
6
7
8
9
10
6
7
8
10
5
4
9
10
9
6
7
8
10
5
4
9
3
1
2
2
3
CAUTION:
Be sure to turn off power switch.
– Pass thread from back to the front through the
thread guide (1).
– Thread the pre-tension guide by pulling the
thread towards the right until it slips under guide
(2). Then pull thread along the right side of pre-
tension as illustrated.
– While holding thread with fingers, pass it
between the tension discs and pull thread down
to make certain it is properly located in between
the tension discs (3).
