Bernette Funlock B42 - Threading the Chainstitch;Coverstitch Looper (Violet)

16
Threading the Chainstitch/
Coverstitch Looper (Violet)
– Raise the presser foot to open the tension
discs.
– Thread the chainstitch/coverstitch looper as
indicated (1)–(11).
9
10
11
2
3
8
6
4
5
7
1
1
2
2
3
3
9
10
11
2
3
8
6
4
5
7
1
1
2
2
3
3
CAUTION:
Be sure to turn off power switch.
– Pass thread from back to the front through the
thread guide (1).
– Thread the pre-tension guide by pulling the
thread towards the left until it slips under guide
(2). Then pull thread along the right side of pre-
tension as illustrated.
– While holding thread with fingers, pass it
between the tension discs and pull thread down
to make certain it is properly located in between
the tension discs (3).
