17
• Insert the bobbin
Put one bobbin on the bobbin winder spindle. Place a bob-
bin in the bobbin holder with the thread running off counter-
clockwise.
End of thread
Guide the thread into the first notch on the front side of
the bobbin holder.
Notch
Draw the thread to the left, sliding it between the tension
spring blades.
Continue to draw the thread lightly until the thread slips into
the second notch . Pull out about 6˝ (15 cm) of thread.
Notch
Attach the hook cover plate. Check the threading. Refer to
the diagram shown on the hook cover plate.
Threading diagramm
