Bernina Bernette b79 - Centering Designs in the Hoop; Checking and Verifying Motif Size

Centering a Combined Design In the Hoop
Check Motif Size
check
A new design that is opened on the screen will come in centered in the hoop. But if you have
combined designs, or have perhaps moved the design around on the screen, the design will
need to be centered in the hoop before sending the design to be stitched.
Check, also known as Trace, is used to conrm the stitching area of a selected motif. After adjusting the
position of a design within the hoop, use this feature to conrm that the design will stitch in the correct
area and to verify placement of the embroidery motif on a project. Note: The b70 DECO also has a dedicated
button on the outside of the machine to easily access this feature.
HOW
Do you know how to:
• Access the check feature in the machine?
• Move the design to ensure correct
placement?
1. Using the same design from the previous page, select the
bottom-most layer to select the entire design.
2. Touch the Move Motif icon.
3. Touch the Centering icon. (Alternatively, you could touch
the X and Y icons to reset at 0.)
4. The design is now centered in the hoop.
1. Fabric and stabilizer should be hooped. Attach the hoop
to the machine.
2.
Select “i”; then select Check Motif Size.
3. Touch each corner arrow to move the needle to the outer
corners of the design in a box fashion. This provides a
method to verify placement and size of the embroidery
motif on a project. Use the Multi-function knobs to ne-
tune placement.
4. Touch the Motif Center icon and the needle will move to
the center of the design. Use the Multi-function knobs to
ne-tune placement as you align the center needle posi-
tion with marked center lines on the fabric.
5. Close the screen to return to the editing screen.
6. Proceed to next page.
17
bernette EMBROIDERY MACHINE WORK BOOK
