Workbook 4—Embroidery Basics
Machine/Module Set-up
BERNINA 750, 770, 780, 790 & 880 Tips
 The slide-on table must not be attached while
the embroidery module is being attached or
removed.
 Make sure there is enough space around the
machine and embroidery module to allow the
unimpeded movement of the embroidery arm.
 Always separate the machine and embroidery
module from one another before transporting
– do not transport as a single unit.
BERNINA 560 & 580 Embroidery Module
 Module Connection Cable
- Stored on the bottom back edge of the module
- Make sure the FLAT side of the cable plug is to
the FRONT
 Attaching the Module
- Place the machine on a flat surface (such as a
table or countertop)
- Place the module on the machine behind the free
arm
- Slide module on from left until lugs engage in
base plate
 Removing Module
- Remove cable plug from sewing/embroidery
computer
- Lift module slightly (do NOT use the embroidery
arm to lift the module!); slide the module to the left
BERNINA 750 QE, 770 QE, 780, 790, 880
Embroidery Module
 Attaching the Module
- Place the machine on a flat surface (such as a
table or countertop) sturdy enough to support the
weight of the machine without sagging
- Slide the module at an angle from left to right to
attach
 Removing Module
- Detach by lifting left end and sliding to the left
BERNINA 560 and 580 Tips
 When connecting the embroidery module,
make sure that the machine and module are
on a flat and even surface.
 Make sure that there is enough space around
the sewing computer and embroidery module
to allow the unimpeded movement of the
embroidery arm.
 Always separate the module and sewing
computer for transporting—never transport
them as a single unit.
