Adjustments and settings
Stitch length
004:
• Turn power switch to “O”.
• Open cloth plate, loosen knob and adjust to desired
length. Tighten knob and close cloth plate.
004D:
• Turn dial to stitch length desired can be adjusted
while sewing.
The stitch length is infinitely variable from 1-4 mm. Most
overlock work is done with a basic setting of 2-3 mm.
Cutting width
• Turn power switch to “0”.
• Raise the upper knife.
• Open the cloth plate.
• Turn cutting width adjustments knob in the direction
desired.
• Lower upper knife.
• Close cloth plate.
The position of the lower knife determines the width of
the seam.
1=3.5 mm seam width
2=4.5 mm seam width
3=5.7 mm seam width
Reduce the cutting width if the edges of fine fabrics curl up
when being sewn. Adjust the cutting knob to a higher
number (A).
Increase the cutting width knob to a higher number (B).
18
