Bernini Be242 - Page 17

Be242 Be242RB Be242-22 OEM's Manual V4.X.XX - March - 2023 page 17
17
Table 7.09 - Output Options Table
Option & description
Option & description
[ 0 ]
Output is disabled
[32]
Alarm from Input 2: Shutdown/Warning
[ 1 ]
Under Frequency Shutdown
[33]
Alarm from Input 3: Shutdown/Warning
[ 2 ]
Over Frequency Shutdown
[34]
Alarm from Input 4: Shutdown/Warning
[ 3 ]
Over Current Shutdown
[35]
NOT USED
[ 4 ]
Over Current Warning
[36]
NOT USED
[ 5 ]
Overload Warning or Shutdown (^^^)
[37]
Cumulative Alternator Alarms
[ 6 ]
Over Voltage Shutdown
[38]
Common Fuel Alarms
[ 7 ]
Under Voltage Shutdown
[39]
HORN
[ 8 ]
Alternator Failure Shutdown
[40]
Crank Delay (Start Warning)
[ 9 ]
NOT USED
[41]
Presence of Nominal Mains Parameters
[10]
Low Oil Pressure Shutdown
[42]
Mains Failure Timing
[11]
NOT USED
[43]
Mains Restore Timing
[12]
NOT USED
[44]
KG Status
[13]
Temperature Switch Shutdown
[45]
KM Status
[14]
NOT USED
[46]
Pre-glow MODE 1/2/3/4
[15]
Low Battery Voltage Warning
[47]
NOT USED
[16]
High Battery Voltage Warning
[48]
RENT<48h
[17]
Low Fuel Shutdown (switch)
[49]
RENT=0h (Expired)
[18]
NOT USED
[50]
Engine Running Status
[19]
Fuel Reserve Warning (switch)
[51]
Presence of Nominal Generator Voltage
[20]
NOT USED
[52]
Be242 in OFF MODE (Status)
[21]
NOT USED
[53]
Be242 in MANUAL MODE (Status)
[22]
Emergency Stop Shutdown (Er08)
[54]
Be242 in AUTO MODE (Status)
[23]
Stop Push button Used in AUTO (Er09)
[55]
Be242 in TEST MODE (Status)
[24]
Maintenance SERVICE 1 (Er10)
[56]
Be242 in LOCK MODE (Status)
[25]
Maintenance SERVICE 2 (Er10)
[57]
Be242 runs the Automatic Periodic Test
[26]
Maintenance SERVICE 3 (Er10)
[58]
Cooling Timing
[27]
Engine Belt Break Shutdown
[59]
Warm-up Timing
[28]
Fail To START Shutdown
[60]
Cycling mode (Logical OR of engine running and
stop solenoid)
[29]
Fail To STOP Shutdown
[61]
Start Pilot repeat output (it repeats the crank output
terminal #9)
[30]
Idle Speed (see section 16.60)
-
--
[31]
NOT USED
-
--
