6 K44 Technical manual
Wiring
The numbers refer to the diagram on the right.
1
Electric locking device. Dashed line refers to
locks with failsafe function.
2
Voltage feed in, terminal block nos. 1 and 2.
3
Contact for zero opening. Close terminal
block nos 6 and 7 (or 13).
4
Timing from external time clock. Input 1:
close terminal block nos. 9 and 7 (or 13).
Input 2: close nos. 8 and 7 (or 13).
5
Remote opening button. Close terminal
block pos. 10 and 7 (or 13).
6
Door bell. Output for activating a buzzer or
similar. Always use relay E7 (connect
between nos. 11 and 2(+).
7
Duress. Output for activating e.g. an alarm.
Always use relay E7 (connect between nos.
12 and 2(+).
8
Tamper switch. Normally closed when the
housing is closed.
9
Extra LED. Max. voltage 30V DC.
1
Remove the jumper if background lighting is
not desired.
11
If the voltage feed is below 20 V, set the
jumper to 12 V.
