TG 500 – Diversity receiver
12
• Frequency group (GR) / Channel (CH)
In the “GR/CH” menu, you can select a predefined (intermodulation-free) frequency
group and a channel from this group.
Press the enter button  to open the submenu.
Press the up  or down button  to select the desired group. Depending on the
frequency band, you can select from up to 8 groups. In each group, the channels are
arranged in irregular frequency intervals. This means that interference between the
transmitters is largely avoided.
Press the enter button  to confirm.
Note: for multi-channel systems, the frequencies must be within one group.
Press the enter button  to so that you can select the desired channel from the
previously selected group. Press the up  or down button  to select the channel.
Press the enter button  to confirm.
• Manual frequency
In the “FREQ MAN” menu, you can manually select any frequency from a
corresponding frequency band in 25kHz increments, regardless of whether it is
stored in a group.
Press the enter button  to open the submenu.
Press the up  or down button  to select the first three figures of the desired
frequency.
Press the enter button  to confirm.
Press the up  or down button  to select the last three figures of the desired
frequency.
Press the enter button  to confirm.
Figure 2-23: Selecting the “Frequency group (GR) /
Channel (CH)” submenu
gr/ch
--/--
Figure 2-24: Selecting the frequency group (GR)
gr/ch
01/01
"
"
"
"
Figure 2-25: Selecting the channel (CH)
gr/ch
01/01
"
"
"
"
Figure 2-26: Selecting the “Frequency” submenu
freq man
794.000
Figure 2-27: Selecting the frequency – first three
figures
freq man
794.000
"
"
"
"
Figure 2-28: Selecting the frequency – last three
figures
freq man
800.000
"
"
"
"
