TG 500 – Diversity receiver
16
• Audiomix – ONLY ON TG 500DR!
If you wish to emit both audio signals (e.g. vocals and guitar),
mixed across both outputs, set the “Audiomix” function to
“ON”.
In the “Gain” menu, you can adjust the volume for each channel
accordingly until you achieve the desired mix.
To use both channels independently of each other, set the
“Audiomix” function to “OFF”.
Press the enter button  to open the submenu.
Press the up  or down button  to activate (ON) or deactivate
(OFF) the “Audiomix” function. Press the enter button  to
confirm.
Figure 2-49: Selecting the “Audiomix” submenu
AudiomiX
oFF
Figure 2-50: Activating/deactivating the Audiomix
AudiomiX
oN
• Squelch
In the “Squelch” menu, you can manually set a squelch, i.e.
an HF level from which the receiver is muted in order to
suppress noise during transmission pauses.
Press the enter button  to open the submenu.
Press the up  or down button  to select the threshold for the
squelch between -80 und -110 dBm.
Press the enter button  to confirm.
Figure 2-51: Selecting the “Squelch” submenu
squelch
-93 b
m
P
Figure 2-52: Setting the squelch
mute at
-93 b
m
P
"
"
"
"
